Blackmagic Design 1&...

Description

Product Highlights
(1) SDI Input, (8) SDI Outputs
3G/HD/SD-SDI Auto-Switching Input
Re-Clocked Outputs
Ancillary Data & Embedded Audio
1080p & 2K Distribution
Supports ASI Signals
Specs
Blackmagic Design Mini Converter Specs
Inputs
1x SDI: Detects & auto-switches between SD-, HD-, and 3G-SDI
Outputs
8x SDI: Automatically match the SDI video input
Re-clocking
Yes
Supported Formats
NTSC, PAL, 720p, 1080i, 1080PsF, 1080p, 2K p, and 2K PsF
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, and SMPTE 425M
Video Sampling
4:2:2 and 4:4:4
Audio Sampling
Television standard sample rate of 48 kHz and 24-bit
Color Precision
4:2:2 and 4:4:4
Color Space
YUV and RGB
ASI Support
Yes
Power Supply
12V universal power supply included
Power Consumption
110V: 40mA220V: 20mA
Voltage Range
12-30V
Packaging Info
Package Weight
1.2 lb
Box Dimensions (LxWxH)
5.6 x 5.4 x 2.6″
