Blackmagic Design Hy...

Description

Product Highlights
1 RU File-Based Video Recorder
Uncompressed & H.264/H.265 10-Bit 4:2:2
Records Compressed in ProRes / DNxHD
1 x 12G-SDI Input, 2 x 12G-SDI Outputs
2 x 2.5″ SSD Slots & 2 x SD Card Slots
1 x HDMI Input, 1 HDMI Output
1 x SDI Loop Output, 1 x USB Type-C Out
Speaker, Remote, 10G Ethernet Port
Front-Panel Buttons, Jog Wheel, LCD
Timecode, Reference & RS-422 In/Out
Specs
Blackmagic Design HyperDeck Studio 4K Pro Specs
Video Input
1 x BNC 12G-SDI1 x HDMI 2.0
Video Output
1 x BNC SDI Loop-Through2 x BNC 12G-SDI1 x SDI Monitor Output1 x HDMI 2.0
Embedded Audio
Input:16 x Channels SDI16 x Channels HDMIOutput:8 x Channels SDI8 x Channels HDMI
Audio Output Connector
1 x 1/4″ Headphone Jack
Network
1 x RJ45, 10 Gb/s
SSD Interface
2 x 2.5″ SATA 3 Gb/s
Reference Input
1 x BNC
Reference Output
1 x BNC
Timecode Input
1 x BNC
Timecode Output
1 x BNC
Device Control
1 x RS-422 Input1 x RS-422 Output
Display Size
2.2″ LCD
Speaker
Mono
Format Support
DCI/UHD 4K 2160p: 30/29.97/25/24/23.982K 1440p: 30/29.97/25/24/23.981080p: 60/50/30/29.97/25/24/23.981080PsF: 30/29.97/25/24/23.981080i: 60/59.94/50720p: 60/59.94/50NTSC/PAL525i 59.94625i 50480p60 and 576p50 via HDMI Only
Supported Operating Systems
macOS 10.15 CatalinamacOS 11.1 Big Sur or LaterWindows 10, 64-Bit
Other Outputs
1 x USB 3.1 Gen 2 Type-C for External Recording or Webcam Use
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2084, and SMPTE 2108-1
SDI Metadata Support
HD RP188 and closed captioning CEA-708HDR Metadata Supported on SDI
Sampling
Video: 4:2:2 YUVAudio: 24-Bit, 48 kHz
Color Precision
10-Bit
Color Space
REC 601, REC 709, REC 20203D LUTS can be Applied to SDI Monitor Out
Multiple Rate Support
Autodetection of SD, HD, 6G-SDI, and 12G-SDI
HDR Support
Hybrid Log Gamma, ST2084 300, ST2084 500, ST2084 800, ST2084 1000, ST2084 2000, ST2084 4000, ST2084
Codecs Supported
ProRes HQ QuickTimeProRes 422 QuickTimeProRes LT QuickTimeProRes Proxy QuickTime for all Formats up to 2160p30Playback Only of:ProRes 4444 QuickTime up to 1080p60 with Auto Routing of Fill and Key over SDI A and B OutputsDNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD Formats up to 60 fpsDNxHR HQX, DNxHR HQX MXF, DNxHR SQ, DNxHR SQ MXF, DNxHR LB, DNxHR LB MXF for 2K DCI and 2160p Formats up to 30 fpsH.265 SDI 4:2:2 10-Bit, H.265 High 4:2:0 10-Bit, H.265 Medium 4:2:0 10-Bit, H.265 Low 4:2:0 10-Bit for all 2160p Formats up to 60 fpsH.264 SDI 4:2:2 10-Bit, H.264 High 4:2:0 8-Bit, H.264 Medium 4:2:0 8-Bit, H.264 Low 4:2:0 8-Bit for all Progressive formats up to 1080p60
Media Slots
2 x 2.5″ SSD2 x SD Card
Rack Size
1 RU
Power Input
1 x 110 to 240 VAC, 50/60 Hz Power Input1 x 12 VDC, 4-Pin XLR Input
Power Consumption
100 W Maximum
Operating Temperature
32to 104°F/ 0 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Relative Humidity
0 to 90% Non-Condensing
Dimensions
19 x 9.3 x 1.74″ / 48.3 x 23.6 x 4.4 cm
Weight
5.57 lb / 2.5 kg
