Blackmagic Design Mi...

Description

Product Highlights
SD/HD/3G-SDI Input
HDMI and SDI Loop Outputs
Supports SD and HD Signals
Automatic Input Signal Detection

Specs
Blackmagic Design SDI To HDMI Converter Specs
I/O
1 x SD/HD/3G-SDI BNC input1 x SD/HD/3G-SDI BNC loop output1 x HDMI type A output1 x USB Micro-B
Format Support
1080p24/25/29.97/30/50/59.941080PsF25/29.97/301080i50/59.94/60720p50/59.94/60NTSCPAL
SDI Compliance
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M
Color Precision
4:2:2
Color Space
YUV and RGB
OS Support
Mac OS X 10.10, 10.11 or laterWindows 8.1, 10
Power
Power input: 5 VDC via USB Micro-BPower consumption: 1.6 WOperational voltage range: 4.4 to 5.25 VDC
Environmental
Operating temperature: 32 to 104°F / 0 to 40°CStorage temperature: -4 to 140°F / -20 to 60°CRelative humidity: 0 to 90% non-condensing
Dimensions
3 x 1.8 x 1″ / 76 x 46 x 25 mm
Weight
5.3 oz / 150 g
Packaging Info
Package Weight
0.825 lb
Box Dimensions (LxWxH)
5.8 x 4.25 x 2.85″
